C22 Casing Spools

The C22 Casing Spool is a wellhead component that provides a means to support and seal an intermediate casing string. The upper section has a straight type bowl and a 45 degree load shoulder to support the production casing string. The lower section houses a secondary seal to isolate the two casing strings and provide a means to test the wellhead seals.

●  Provides an attachment and sealing point to the surface casing.

●  Allows for support and testing of a BOP system while drilling out for the next casing string.

●  Provides a casing hanger load shoulder and bowl for hanging and sealing of the next casing string.

●  The load shoulder and bowl also accommodate BOP test plugs.

●  Provides two outlets for annular access and monitoring.

●  Provides a means for Wear Bushing installation and retention.

●  C-29 bowls available for extreme casing loads.

●  Both accept C-21 and C-21-P Casing Hangers for low weight situations.
